Product Name：Waterproof dustproof metal keypad
Product P/N：GZB016010
Product dimension：88*72mm
Product Description: It is stainless steel keypad of waterproof and dustproof, adopt rubber design,
and with digital keys and 2function keys, the keys are compactlayout and it with 2.0mm long-travel. It can be installed from horizontal direction and vertical direction. It adopts
the design of whole stainless steel overlay, rubber keys and with the precision tooling, the surface treatment beautiful and magnificent.
Product Application：
It mainly applied to various kinds of place of no regulation or semi-regulation information
terminal.For example Internet terminal, University, Market, Hotel, Bank, Airport, Station, and
another information station of public place, Automatic ticket rendor, Gas station, Automatic Teller
Machine(ATM), Public telephone ect.
Mainly Features：
1. Both of stainless steel panel and keys can good protect to avoid the deter vandals, even
under bad condition, it still can work well.
2 It is adopted rubber assembling, Effective for waterproof effect.
3. After the keypad is installed, it is looks beautiful and generous, plug and play.
4.Metal keypad surface is good to guard from thieves, and it is difficult to bending and be out, so
it can prevent key off and damage.
5.We can customer made all kinds of keypad with multiple languages as per the customer’s needed.
can meet varying country and make different styles.
6.It is easy for installation, supply USB interface mode to contact the host computer for
keypad operation.
Mechanical Specifications：
1. Key: It is with 12 keys, and use port printing-brush SUS304 stainless steel material.
2. Design of the key: Square Key with character of laser engraving and corrosion.
3. Key Size: 13.8mm*13.8mm，
4. Key`s travel ：2.0mm
5. Lifetime of the key: Operating more than 2Million per key.
6. Strength of the key: 1.2N+/-0.1N (Contact with strength)
7. Front Panel: import printing-brush SUS304 stainless steel with 1.5mm thickness.
Electric parameter：
1. Operating current: Direct current+5V/-5%
2 working current：20mA
3 Expected life-time：>5yer
4. Button switch technology: imported gilded metal dome
5. Interface Technology：USB6. Operating System：DOS/Windows95/98/NT/ME/2000/2003/XP/Vista, Linux, Unix, Mac osx
Environmental adaptation：
1. Operating Temperature：-20℃to+60℃
2. Storage Temperature：-30℃to+70℃
3. Relative Humidity: 30-90%
